Automatic Up-down multi-blades rip saw



BriefSuzhou Gaojing CNC Machinery Co.,Ltd is focused on selling wood working machinery for more than 6 years. We devoted ourselves to edge banding machine, drilling center, machining center. The following is about Automatic Up-down multi-blades rip saw , we hope to help you better understand of it.



Automatic Up-down multi-blades rip saw  professional solution: upper and bottom two saws make multi chip rip cut vertically, for under 180mm thick and 300mm wide wood. Equipped with up and down 3 groups of anti-rebound safety devices, protecting the workers. The feeding wheels with tooth ensure the smooth feed flowing.



Automatic up -down multi-blades rip saw Product description



Working thickness

10180mm

Working thickness(with outer fence)

45180mm

Max. working width

300mm

Min. working length(next to each other/single)

450/635mm

Feeding speed

418m/min

Spindle dia

φ50mm

Spindle speed

4000r/min

Upper blade dia

 φ250-φ305mm

Bottom blade dia

φ250-φ305mm

Total power

64.5kW

upper spindle motor

30kW

bottom spindle motor

30kW

spindle lifting motor

0.37kw*2

feeding motor

3.0kW

beam lifting motor

0.75kW

Upper feed wheel dia

 φ140×φ35mm

Dust outlet

 φ150×3

Table height

860mm

Dimension(L*W*H)

295×162×177cm

Weight

3300Kg

1. The machine body(frame) is made of cast iron.

2. The upper and bottom spindles are with electric-lifting.

3. Feeding speed is controlled by variator.

4. Equipped with outer fence, in case for off tracking

5. Equipped with upper and bottom anti-kick back fingers for operator   safety.





Note: all above pictures and parameters are subject to the real product. We reserve the right to improve the product.
